Coriolis mass flowmeter for universal applications and process control
Evaluation kit for the single-use liquid flow sensor LD20-2600B. The LD20-2600B single-use liquid flow sensor for fast, precise and reliable measurements of the lowest flow rates in biomedical applications was successfully launched three years ago. Pimpri Chinchwad traffic department have started helpline if residents are charged auto fare more than meter rate or if autorickshaw driver decline to ply by meter. Auto fare in PCMC 1. Apr 21, 2013 Samsung Galaxy S4 Toolkit XDA:DevDB Information Galaxy S4 Toolkit, a Tool/Utility for the Samsung Galaxy S 4 Contributors KINGbabasula, Version Informatio.
- Mass, density and volume flow of gases and liquids; maintains operation over a wide range of gas fractions and complex flow conditions (EGMTM)
- Also certified for hygienic use
- Flange: DN15…100 / ½…4', max. PN100 / ASME Cl 600; many hygienic fittings
- 3 x 4…20 mA, HART®7, FF, Profibus-PA/DP, Modbus, PROFINET, Bluetooth®
OPTIMASS 1400 C – Compact version with flange
The OPTIMASS 1400 is a cost-effective twin straight tube Coriolis mass flowmeter for a wide range of standard applications with gases and liquids (up to 170,000 kg/h or 6,235 lb/min). The meter features Entrained Gas Management (EGMTM) for liquid applications and thus maintains operation even with entrained gas of up to 100%.
The OPTIMASS 1400 features an optimised flow splitter for minimum pressure loss and can be drained and cleaned easily. Next to flange process connections it supports a wide range of standard hygienic connections for food and beverage applications. Like with all other KROHNE Coriolis mass flowmeters there are no installation restrictions as the OPTIMASS 1400 is not affected by crosstalk/line vibrations and can thus be installed in series or in parallel. It is also approved for use in hazardous areas. The Coriolis mass flowmeter provides enhanced diagnostics (NE 107) and comes with various digital communication options. Via the OPTICHECK Flow Mobile app all device settings can be managed on-site via a secure Bluetooth® connection. In this way, a variety of commissioning tasks, e.g. zero calibration or configuration of diagnostics, can be done wirelessly.
Product highlights
- Twin straight tube design
- Entrained Gas Management (EGMTM): meter maintains operation with air or gas entrainments in the medium
- Device commissioning, verification, diagnostics and monitoring via a secure wireless Bluetooth® connection (<20 m / 65.6 ft)
- Fast and completely digital signal processing
- Best-in-class price/performance ratio
- High accuracy mass, density and volume flow measurement (±0.15% of MV)
- Extensive sensor and process diagnostics (incl. NE 107)
- Integrated temperature measurement
- Optimised flow splitter for low pressure loss
- Optional PED approved secondary pressure containment up to 100 barg / 1450 psig
- Optional insulation, heating jacket or purge ports
- No crosstalk: resistant to installation and process effects
- On-site verification of flowmeter with OPTICHECK service tool
Typical applications
General
Drivers S4 Meter Tester
- Standard process applications up to 130°C / 266°F
- Measurement of liquids, gases and gas entrained liquids
- Portable installations on trucks, rail tankers, portable rigs etc.
- Applications with very low operating densities (<10 kg/m3)
Food and beverage industry
- Measurement of flow, density, specific gravity in brewing processes
- Flow measurement of beverages and fruit juices
- Dairy products
- Fat, oily and greasy products
- Dosing of additive food components
Pharmaceutical industry
- Batching, dosing, filling
- Solvent extraction
- Ultrapure water ring-main measurement
Chemical and other process industries
- Bulk loading
- Batching to reactors
Marine industry
- Fuel consumption measurement
Pulp and paper industry
- Batching and dosing of additives, bleaches and colourants
Water and wastewater industry
- Flocculant dosing
Product variants
OPTIMASS 1400
Food & Beverage version
Coriolis mass flowmeter for universal applications in the food and beverage industry
- Measurement of mass and volume flow, density and concentration (e.g. Brix, Baume, Plato, alcohol etc.)
- With Entrained Gas Management (EGM™) for applications with aerated products (e.g raw milk, yoghurt, ice cream)
- Drainable and easy to clean; small footprint
- FDA, EC1935/2004 and GB 4806 conform; 3A, EHEDG certified
OPTIMASS 1400
Marine version
Coriolis mass flowmeter for general ship fuel applications in the marine industry
- Measurement of mass and volume flow, density and temperature for fuel consumption monitoring of MGO, MDO and other liquids
- Rugged stainless steel version for the harshest conditions on ships
- Optimised for the EcoMATE™ Fuel consumptionand EcoMATE™ MRV & IMO DCS Emission monitoringsolutions for ships
- Marine approvals: DNV GL, CCS, LR, ABS, RINA, KR
Accessories for this product
OPTICHECK Master
Handheld for in-depth verification, device commissioning and monitoring
- On-site performance check and verification (level 0,1,2) without process interruption
- Convenient commissioning of field devices, e.g. zero calibration
- Detailed reports for proof test documentation of safety loops acc. to IEC 61508/61511, and for quality management systems (ISO 9001)
Drivers S4 Meter Wireless
OPTICHECK DTM
DTM for advanced device verification and commissioning
- Usable with any FDT frame application from the control room or on site
- Advanced verification (level 0,1) without process interruption
- Detailed reports for proof test documentation of safety loops acc. to IEC 61508/61511, and for quality management systems (ISO 9001)
OPTICHECK Mobile
Mobile app for wireless device commissioning, verification and monitoring
- Wireless commissioning and device parametrisation via secure Bluetooth connection
- Verification without measurement interruption
- Monitoring of meter performance and application parameters
- Free download for iOS and Android
Applications
Related products
MFC 400
Coriolis mass flow converter for combination with OPTIMASS Coriolis mass flow sensors
- Compact and remote field housing
- With extensive diagnostics (NE107) and Entrained Gas Management (EGM™) for advanced requirements
- 4-wire, 3 x 4…20 mA, HART®7, Modbus, FF, Profibus-PA/DP, PROFINET
- Secure wireless access via Bluetooth® or remotely via HART® even in safety-related applications
OPTIMASS 1000
Coriolis mass flow sensor for combination with MFC 010 and MFC 400 signal converters
- Twin straight tube design
- Connection sizes: DN15…100 / ½…4'
- Tube material: Duplex stainless steel
Links
KROHNE - Technology you can trust
Related website
Find more information about our safe, reliable and simple to handle process instrumentation for Safety Instrumented Systems and an overview of the KROHNE SIL competence on this dedicated website.
OPTIMASS portfolio
Related website
Explore the technical details and highlights of our OPTIMASS Coriolis flow meter family in an interactive demo that features 360° views plus short video clips.
.jpg "Drivers")
Download Center
OPTIMASS 1000
Download Center
- Technical datasheets and handbooks
- Flyers and brochures
- Certificates and approvals
- Software and driver
